Waterco SupaSkimmer Box

The SupaSkimmer is a large capacity skimmer box deal for large domestic, semi-commercial and commercial swimming pools. Because of its large capacity of 5.9 litre debris collection, it is also ideal for any swimming pool constructed in leafy environments.

Features:-

Lock-down leaf basket and vacuum plate - holds the leaf basket and vacuum plate firm
Large capacity basket – 5.9 litres, over double the size of conventional skimmers
2 x 50mm bottom suction ports – less water flow restrictions
2 x 40mm side ports – ideal for wall mount cleaners
New child-resistant safety lid – prevents child accidents
Deeper body style – less chance of running pumping equipment dry
Built-in overflow drain port to assist the prevention of flooding during heavy rain

Skimmer Box Extension Ring

If the skimmer is to be installed so that the deck lid will not be secured to the skimmer body, Waterco recommends using a skimmer Extension Ring (624105) for trouble free installation. The Extension Ring sits snugly in between the skimmer body and the Deck Ring and is strong enough to hold its shape during concreting. Using the Extension Ring will prevent misalignment of the Deck Ring and the skimmer body. This will eliminate problems caused by concrete intruding into the skimmer box cavity. The Extension Ring will ensure there are no problems inserting/removing vacuum plates or other similar devices. An individual Extension Ring offers an extension of 60mm and can be piggybacked to give further extension of any multiples if required. (eg 120mm , 180mm etc).

Manual

Waterco SupaSkimmer Manual

Brochure

Waterco SupaSkimmer Brochure
